適配器全系方案原廠直供，3W 至60W 迪浦原廠PT2580原邊反饋等效6級 內置MOS 650V 功率 17W 電壓5V 2.4A 代替型號DP2542 SSR-電源管理系列

迪浦PUOLOP原廠直供，中間沒有代理價格，價格優勢，帶原廠技術方案支持

充電器.適配器 LED驅動電 3W到60W 方案，帶技術方案支持，直接原廠工程對接解決

同時生產成品高中低MOS管和單芯片MCU 民業和工業級。霧化器，藍牙耳機，空氣清醒器，小家電，TV電源

電話13682379002

Di pu factory direct, no agent price, price advantage, with original factory technical solution supportLED drive electric charger. Adapter to 60 w 3 w, with technical solutions support, original project docking solution directlyAt the same time production of finished products including MOS tube and single chip MCU industry and industrial grade. Atomizer, bluetooth headset, the air is clear, small appliances, TV power supplyThe phone 13682379002

PT2580類型：原邊反饋能效等級：六級驅動功率管：內置MOS輸出功率： 17W封裝： DIP-7產品特點： 1.低成本、電路簡單2.優異的效率并滿足空載低功耗3.輸出電纜壓降線補4.脈沖頻率調制抑制噪聲5.全電壓85-265V輸入應用領域：手機充電器、智能家居待機電源平板電腦網絡設備適配器等

PT2580Type: the original boundary feedbackEnergy efficiency rating: 6Drive power tube: built-in MOSOutput power: 17 wPackaging: DIP - 7Product features: 1. The low cost, simple circuit2. Excellent efficiency and meet the low no-load power consumption3. The output pressure drop cable line4. The pulse frequency modulation noise5. 85-265 - v input voltageAreas of application: mobile phone charger, smart home standby power adapter tablet computer network equipment, etc

n描述特性 PT2580is performancePrimary很高的家庭方監管(PSR)高的電源開關 精密的簡歷/ CC控制適合充電器應用程序。集成電路也可以支持準諧振(QR)降壓恒流拓?fù)銵ED照明如果選取銷是短暫的接地。在簡歷模式下,PT2580采用多模式控制的混合使用(振幅調制模式和(調頻) 提高系統效率和調頻模式可靠性。在CC模式下,使用PFM控制IC 線和負載CC補償。集成電路可以自由操作和實現音頻噪聲優化的動態響應。內置的電纜下降補償(CDC)功能可以提供優秀簡歷的性能。PT2580集成功能和欠壓保護 鎖定(UVLO), VDD過電壓保護 (VDD OVP),逐周期電流限制 ((OCP),短負載保護(SLP)和VDD ?與650 v MOSFET集成 ?支持的回程和Buck拓?fù)? 回程PSR控制(選取

n Description n FeaturesPT2580is a family of a high performancePrimarySide Regulation (PSR) power switch with highprecision CV/CC control ideal for chargerapplications. The IC can also supportQuasi-Resonant (QR) Buck constant currenttopology for LED lighting if SEL pin is short toGND. In CV mode,PT2580 adopts Multi ModeControl which uses the hybrid of AM (AmplitudeModulation) mode and (Frequency Modulation)FM mode to improve system efficiency andreliability. In CC mode, the IC uses PFM controlwith line and load CC compensation. The IC canachieve audio noise free operation andoptimized dynamic response. The built-in CableDrop Compensation (CDC) function can provideexcellent CV performance. PT2580 integratesfunctions and protections of Under VoltageLockout (UVLO), VDD over Voltage Protection(VDD OVP), Cycle-by-cycle Current Limiting(OCP), Short Load Protection (SLP), and VDD ? Integrated with 650V MOSFET? Support Flyback and Buck Topology: Flyback PSR Control (SEL= Floating) QR-Buck CC Control (SEL= GND)? Multi Mode PSR Control? Audio Noise Free Operation for PSR? Optimized Dynamic Response for PSR? Low Standby Power <70mW? ±4% CC and CV Regulation? Programmable Cable Drop Compensation：(CDC) in PSR CV Mode? Built-in AC Line & Load CC Compensation? Build in Protections: Short Load Protection (SLP) On-Chip Thermal Shutdown (OTP) Cycle-by-Cycle Current Limiting Leading Edge Blanking (LEB) Pin Floating Protection? VDD UVLO OVP & Clamp? Package: DIP-8n Applications? Battery Chargers for Cellular Phones? AC/DC Power Adapter and LED lightings? PSR Application：Clamping.PT2580

、
